Wholesale Heavy Duty Solid Woven Flame Resistant PVC Pvg Conveyor Belt

Get durable and flame resistant wholesale PVC/PVG conveyor belts from our factory. Made with heavy-duty solid woven material for reliable performance.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Parameters
  • Certifications
  • Packaging & Shipping
  • Company Profile
  • Application
Overview

Basic Info.

Model NO.
OEM
Condition
New
Warranty of Core Components
12 Months
Structure
Belt Conveyor
Color
Black
Edge
Mould / Cut
Dimension(L*W*H)
Variable
Logo
Available
Usage
Mining,Cement,Building,Steel etc
Tensile
9-25MPa
Shipping
by Sea
Transport Package
PE Bag
Specification
300~2000mm width
Trademark
TRX
Origin
China
HS Code
4010120000
Production Capacity
5000meters/Month

Product Description

Wholesale heavy duty Solid Woven Flame Resistant PVC PVG Conveyor Belt

Product Description

TRX has developed PVG solid woven belting that offers superior abrasion and impact resistant properties - minimising cover wear and improving operational performance.

The moderately oil resistant PVG compound provides low temperature capabilities. The all-polyester, single-ply interwoven carcass provides low stretch, good fastener retention and tear resistance, all at an economical price.

  • Chemical, static and moisture resistant
  • Using higher quality PVG nitrile cover compounds in combination with PVC carcass increases belt life
  • Using our unique PVG compound mix improves cover adhesion, abrasion and impact resistance
  • Extreme adhesion and flex resistance
  • Minimised corrosion problems
  • Superior fastener holding ability
  • Resistance to idler junction failures
Wholesale Heavy Duty Solid Woven Flame Resistant PVC Pvg Conveyor Belt
Product Parameters


Suitable for applications in dry conditions at an angle of less than 16 degrees.
Cover thickness can be from 0.5 to 4 mm.
Nitrile Covered PVG type:
Suitable for applications at a slope angle of less than 20 degrees, and thickness can be 1 to 8 mm.
Resistance to wetness, slip, low temperature and weariness
Standards: MT914, BS3289 and HG2805

Specification:

TYPE

TENSILE STRENGTH N/mm

Break elongation (%)

Tear strength N≥

Longitudinal≥

Transverse≥

Longitudinal≥

Transverse≥

PVC/PVG680

680

265

15

18

1091

PVC/PVG800

800

280

15

18

1180

PVC/PVG1000

1000

300

15

18

1180

PVC/PVG1250

1250

350

15

18

1540

PVC/PVG1400

1400

350

15

18

1540

PVC/PVG1600

1600

400

15

18



PVC/PVG1800

1800

400

15

18



PVC/PVG2000S

2000

400

15

18



PVC/PVG2240S

2240

450

15

18


Woven fabric:

Wholesale Heavy Duty Solid Woven Flame Resistant PVC Pvg Conveyor Belt
Certifications
Wholesale Heavy Duty Solid Woven Flame Resistant PVC Pvg Conveyor Belt



Packaging & Shipping

Packaging Details:

PVC water-proof cloth, wooden box, Steel fram.
Wholesale Heavy Duty Solid Woven Flame Resistant PVC Pvg Conveyor Belt


Wholesale Heavy Duty Solid Woven Flame Resistant PVC Pvg Conveyor Belt

Company Profile

Hebei TRX Rubber Products Co., Ltd is a leading professional manufacturer of conveyor belts & conveyor accessories in China. The main workshops cover 20,000 square meters in the total 60,000 square meters of the plant. The applied technology and equipment in the advanced production lines are state of the art in the industry. The sales headquarters is located in the capital of China, Beijing with branches in domestic and abroad.

It specializes in following three series: 1) Heavy-duty Conveyor Belt, including universal EP/NN and CC Belt, Chevron Belt, Oil Resistant Belt, Abrasion Resistant Belt, Heat Resistant Belt, Fire Resistant Belt, Chemical Resistant Belt, Sidewall Belt, Flat Transmission Belts, 2) Rubber Sheets, including SBR, NBR, NR, CR, EDPM, Rubber With Insertion 3) Conveyor accessories. These three series of products conform to RMA, DIN, ASTM and ISO specifications.

Its products, honored with "The most Advanced level of Products" by the Committee of Science and Technology, have been widely used in mining and quarrying, power stations, steel plants, bulk cargo terminals, cement industry, and other material handling fields. With great success in domestic market, it has been focusing on global market with several hundreds of foreign valued customers in Asia, South America, North America, Africa and Europe.

The company mission:

1.Supply one-stop outstanding service to global customers.
2. Engage in complete solutions with conveyor belting and power transmission belting.
3. Persist in technology improvement and quality control in the whole process of production and service.
Wholesale Heavy Duty Solid Woven Flame Resistant PVC Pvg Conveyor Belt
Wholesale Heavy Duty Solid Woven Flame Resistant PVC Pvg Conveyor Belt
Application

Some of the areas of application include for meeting the transportation demands of:


Wood Chips Sand & Gravel
Heavy Duty Scrap metal Minerals - Coal & Ore
Materials - Fine Coal & Grains Waste & Recycling Plants
Road Construction Crushing Industries
Bagged Materials Steel Pellets


Wholesale Heavy Duty Solid Woven Flame Resistant PVC Pvg Conveyor Belt
