Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt

Shop the best quality Rubber Conveyor Belt for Coal Industrial at our factory. Choose EP Rubber Conveyor Belt for durable and efficient performance.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • International Standard
  • Contact us for inquiry
  • You may also Like
  • Our Advantages
  • Welcome Visit Us
  • FAQ
Overview

Basic Info.

Model NO.
EP Conveyor belt for abrasion 90mm3
Thickness
3-25mm
Model Number
Ep100,Ep125,Ep150,Ep200,Ep250,Ep300 Ep400
Standards
DIN22102, BS490, As1332, Rma, Jisk6322, SABS1173 E
Name
Duty Ep 5 Ply Rubber Conveyor Belt Tape for Cement
Surface
Flat Belt
Edge
Molded Edge and Cut Edge
Materials
Ep Conveyor Belt
Fabric Layers
1-10ply
Application Industry
Coal, Mining, Port, Metallurgy, Electric Power, CH
Surface Rubber
Top Rubber:0-10mm Bottom Rubber:0-6mm
Samples
Free
After- Sale Service
24 Hours All Day by E-Mail or Call
Spec
P 1000/4 6 + 3 mm, 1200mm Width, X Conveyor Belt
Classification
Rubber Conveyor Belt
Transport Package
PP Package / Wooden Pallets/ Steel Shelf
Specification
EP400/3, EP500/3, EP500/4. EP640/4
Trademark
ZHENXING
Origin
Shandong, China
HS Code
4010120000
Production Capacity
150000meter/Month

Product Description

Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt

We are a nation chemical designated enterprise in rubber conveyor belt line and ISO certified manufacturer and exporter of superior quality  conveyor belts, which are also called as conveyor belting. These conveyor belts are compatible with long distance conveying with high load, speed & impact. These conveyor belt find usage in diverse industries for material handling applications.

  Supply characteristics

*Do not need to order by whole roll, length and width can be customized .

*Drill hole service can be provided to make install and usage easy
.

Product Description

Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt

Application of EP conveyor belt:

  • Sand, gravel, stone industry
  • Cement, concrete plants
  • Heating and power stations, garbage incineration plants
  • Road construction machinery
  • Recycling, compost industry, mineral processing plants
  • Timber industry and sawmills
  • Slag conveyors
  • REA-gypsum
  • Broken glass
  • Silica sand or materials containing silica sand
  • Ascending conveyors with slipping type of material



  A conveyor belt is the carrying medium of a belt conveyor system, one of the many types of conveyor systems available today. Each conveyor system requires different modules in order to function properly and do the tasks required by the belts.




Application Environment

Heat resistant conveyor belt is mainly used to transport high temperature materials, such as sintering ore, hot coke, clinker, hot casting and so on. According to the manifestation of the heat resistant belt breakage until to lose transportation ability and the heat resistant grading, we use EPDM or SBR as the covering layer rubber, and high modulus low shrinkage polyester or cotton canvas as the strong layer. It can use the heat resistant woven glass fabric between the cover rubber and the layers, so as to improve the working life of the heat resistant conveyor belt. We can make it into endless conveyor belt as per the clients' requirements.

Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt

Rubber conveyor belt

Conveyor belt is widely used in agriculture, industrial and mining industry and transportation industry. The structure of conveyor belt is mainly composed of tensile layer and covering rubber. The tensile layer is divided into fabric and metal. EP conveyor belt is widely used in the industrial field.

    International Standard

    Cover Grades Applicable Standards Min. Tensile Strength Min. Elongation at Break Max. Abrasion Loss
    (MPa) (%) (mm)
    DIN-Z DIN 22102 15 350 250
    RMA-2 RMA 14 400 200
    ISO-L ISO 10247 15 350 200
    IS-N-17 IS 1891 17 400 200
    AS-N AS 1332 17 400 200
    ARPM RMA-2 ARPM 14 400 175
    SANS-N SANS 1173 17 400 150
    RMA-1 RMA 17 400 150
    DIN Y DIN 22102 20 400 150
    SANS-C SANS 1173 20 400 150
    IS-M-24 IS 1891 24 450 150
    ARPM RMA-1 ARPM 17 400 125
    AS-M AS 1332 24 450 125
    ISO-H ISO 10247 24 450 120
    SANS-M SANS 1173 25 450 120
    DIN X DIN 22102 25 450 120
    ISO-D ISO 10247 18 400 100
    DIN-W /HAR DIN 22102 18 400 90
    SANS-A SANS 1173 18 400 70
    AS-A / SAR AS 1332 17 400 70

    Multiply Textile Reinforced Rubber Conveyor Belts are available in below listed fabric styles.



    Contact us for inquiry

    Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt
    We will be appreciated if you can provide the following specification:

    1. Conveyor belt type
    2. Top cover thickness
    3. Bottom cover thickness
    4. No.of plies
    5. Width of the conveyor belt
    6. Grade:

    If you are not sure for any of above,we can recommend for you.
    Once we get above information we will quote exact price at soonest time.

    You may also Like



    Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt
    Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt
    Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt

    Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt
    Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt
    Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt


    Our Advantages

    Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt

    Welcome Visit Us



    Rubber Conveyor Belt for Coal Industrial Conveyor Belt Ep Rubber Conveyor Belt

    FAQ

    (1)Q: Are you a factory or trading company?
    A: We are a factory with an export license. We have the most convenient transportation conditions.

    (2)Q: Do you offer samples?
    A: We are glad to offer you free samples. New clients are expected to pay for the delivery cost, this charge will be deducted from the payment for the order.

    (3)Q: How about the lead time?
    A: Within10-20 days after getting the prepayment or L/C.

    (4)Q: How can we pay?
    A: For a small sample shipping costs, you can pay either by PayPal or by T/T. And by T/T or L/C at sight for a large amount of the order.

    (5)Q: Can you do CO, Form E, Form F, Form A, etc?
    A: Yes, we can do them for you.

    (6)
    Q: What is your factory's main product?

    No. Rubber Conveyor Belt
    1 Conveyor Belt for General Purpose
    1.1 EP(polyester) Conveyor Belt:
    EP100,EP125,EP150,EP200,EP250,EP300,EP400,EP500,EP630
    1.2 NN(Nylon) Conveyor Belt :
    NN100,NN125,NN150,NN200,NN250,NN300,NN400,NN500,NN630
    1.3 Cotton Conveyor Belt:
    CC-56 CC70
    1.4 Steel Cord Conveyor Belt:
    ST630,ST800,ST1000,ST1250,ST1600,ST2000,ST2500,ST3150,ST4000,ST4500,ST5000,
    ST5400
    2 Conveyor Belt for Special Purpose
    2.1 Heat Resistant Conveyor Belt
    2.2 High-Temperature Conveyor Belt
    2.3 Fire Retardant Conveyor Belt
    2.4 Cold Resistant Conveyor Belt
    2.5 Oil Resistant Conveyor Belt
    2.6 Chemical Resistant Conveyor Belt
    3 Chevron (PaConveyor Belt
    4 Bucket Elevator Conveyor Belt
    5 Sidewall Conveyor Belt
    6 Flat Transmission Belt
