Product′s Name
Linear, Linear Motion Guideway, Linear Guide
Model Number
HGH25ca
Grade
C/H/P
Type
High Assembly
Dimensions of Assembly Height
40mm
Dimensions of Block Thread
M6*8
Dimensions of Block B/C
35/35
Bearing Material
S55c, Bearing Steel, Carbon Steel, Stainless Steel
Moving Structure
Slide Rail + Slide Block
Linear Guide Length
100~4000mm
Load Type
Medium Load
Core Components
Bearing Steel Ball
Performance
High Precision Low Noise
Package
Neutral Plastic Bag+Neutral Box/Carton
Lead Time
7days
Transport Package
Carton or Wooden Case
Specification
HGH
Trademark
WF
Origin
Jiangsu, China (Mainland)
HS Code
8483109000
Production Capacity
10000pieces/Month
Packaging & Delivery
Package Size
100.00cm * 10.00cm * 10.00cm
Package Gross Weight
1.000kg
Product Description
Introduction:
Linear guide is consisted of rail, block, rolling elements, retainer, recirculator, end seal etc. By using the rolling elements, such as balls or rollers between the rail and block, the linear guide can achieve high precision linear motion.Linear guide block is divied to flange type and square type without flange.or Seal type block, Standard type block, Double bearing type block, Short type block. Also,linear block is divided to high load capacity with standard block lenth and ultra high load capacity with longer block length. Catalogue of Linear Guideways:
1.HG SERIES IS A HIGH ASSEMBLED BALL LINEAR GUIDE RAIL;
2.EG SERIES IS A LOW ASSEMBLED BALL LINEAR GUIDE RAIL;
3.RG SERIES IS A LINEAR GUIDE WITH ROLLERS ROLLER TPYE BLOCK,WHICH CAN AFFORD HIGH LOAD;
4.MGN/MGW SERIES IS A SMALL/MINIATURE LINEAR GUIDE RAIL.
Structure of Linear Guideways:
1.Rolling cycle system: slider, guide rail, end cover, steel ball, ball holder;
2.Lubrication system: oil nozzle and tubing joint;
3.Dust-proof system: oil scraper, negative dust seal dust-proof sheet, guide rail bolt cover, metal scrap
Advantages of Linear Guideways:
1.Easy to install ,direct locking with screw and worktable;
2.Design of the ball arrange to upgrade weight bearing capacity;
3.Long life with high speed,high accuracy and linear motion;
4.High speed, low noise;
5.High rigidity ,multiple precision
Applicable Industries:
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Printing Shops, Construction works , Advertising Company, Others.
1.HG SERIES IS A HIGH ASSEMBLED BALL LINEAR GUIDE RAIL;
2.EG SERIES IS A LOW ASSEMBLED BALL LINEAR GUIDE RAIL;
3.RG SERIES IS A LINEAR GUIDE WITH ROLLERS ROLLER TPYE BLOCK,WHICH CAN AFFORD HIGH LOAD;
4.MGN/MGW SERIES IS A SMALL/MINIATURE LINEAR GUIDE RAIL.
Structure of Linear Guideways:
1.Rolling cycle system: slider, guide rail, end cover, steel ball, ball holder;
2.Lubrication system: oil nozzle and tubing joint;
3.Dust-proof system: oil scraper, negative dust seal dust-proof sheet, guide rail bolt cover, metal scrap
Advantages of Linear Guideways:
1.Easy to install ,direct locking with screw and worktable;
2.Design of the ball arrange to upgrade weight bearing capacity;
3.Long life with high speed,high accuracy and linear motion;
4.High speed, low noise;
5.High rigidity ,multiple precision
Applicable Industries:
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Printing Shops, Construction works , Advertising Company, Others.
Regular specifications as follows table:
| HGHCA/HA Series | HGLCA/HA Series | HGWCC/HC Series |
| HGH15CA/HGH15HA | HGL15CA/HGL15HA | HGW15CC/HGW15HC |
| HGH20CA/HGH20HA | HGL25CA/HGL25HA | HGW20CC/HGW20HC |
| HGH25CA/HGH25HA | HGL30CA/HGL30HA | HGW25CC/HGW25HC |
| HGH30CA/HGH30HA | HGL35CA/HGL35HA | HGW30CC/HGW30HC |
| HGH35CA/HGH35HA | HGL45CA/HGL45HA | HGW35CC/HGW35HC |
| HGH45CA/HGH45HA | HGL55CA/HGL55HA | HGW45CC/HGW45HC |
| HGH55CA/HGH55HA | | HGW55CC/HGW55HC |
| HGH65CA/HGH65HA | | HGW65CC/HGW65HC |
Kindly pls contact service, if you have any problem, thank you!!!!!!!!!!!!!
